Cables and metal stamping parts

The Cable & Wire Industry mainly involves metal drawing (for manufacturing wires) and extrusion (for creating insulation layers). However, in the stages of cable assembly, connection technology, and





The Cable & Wire Industry mainly involves metal drawing (for manufacturing wires) and extrusion (for creating insulation layers). However, in the stages of cable assembly, connection technology, and cable laying, metal stamping parts play a decisive role. The cables are responsible for "transmission", while the stamped parts are responsible for "connection" and "fixation". Without the stamped parts, the cables would merely be an isolated wire that cannot be connected to any device. The following are the specific roles and application scenarios of metal stamping parts in the cable industry:



1.Terminals & Contacts —— The "hands" of cables This is the most core and widely used application of stamping parts in the cable industry. The ends of cables must be connected to circuit boards, batteries or devices through terminals. Crimp Terminals: Shape: Ring, Fork, Pin, Spade. Process: Usually made by high-speed stamping of copper or brass strips, and then coated with tin or silver on the surface. Function: By using a crimping pliers, the tail end of the terminal is deformed to firmly grip the copper wire of the cable, and the front end is fixed to the equipment with screws. Connector Pins/Sockets: Form: The tiny metal pins and tabs hidden inside USB cables, HDMI cables, and car wiring connectors. Process: Precision high-speed stamping. Extremely high dimensional accuracy and elasticity are required (usually using phosphor bronze or beryllium copper) to ensure good contact after thousands of insertions and extractions. Cable Lugs: Form: A large connector for thick cables (such as power cables). Process: Made by stamping, flattening and punching thick copper tubes or plates.



2. Cable Management - the "steward" of cables Cables cannot be scattered randomly inside equipment or buildings, and need to be fixed with stamped parts. Cable Clamps: Function: Fix the wiring harness on the chassis wall or wall surface. Process: Steel strip stamping and bending, usually used in conjunction with rubber gaskets to prevent cable wear. Metal Cable Ties: Function: Use stainless steel stamped zip ties to tie cables in ships, outdoors, or high-temperature environments (where plastic zip ties may age and break). Process: Stainless steel strip stamping, with a special ball locking structure on the head. Strain Relief: Function: Installed at the entrance of the cable entering the casing, it clamps the cable to prevent external pulling from causing internal solder joints to break.

3. Shielding&Grounding - the "bodyguards" of signals Anti interference is crucial for cables used for transmitting data, such as coaxial cables and signal lines. Shielding Cans/Clips: Function: To connect the cable to the PCB board, attach a metal stamped cover to prevent EMI leakage or intrusion. Grounding Clips: Function: Puncture the outer skin of the cable to contact the shielding layer, and introduce static electricity into the metal shrapnel on the ground. Tinplate shell: Many cable connectors have a stamped tin liner inside, specifically designed for shielding.

4. IDC - Insulation Displacement Contact This is an efficient connection technology commonly found in Ribbon Cables. IDC terminal: Function: There is no need to peel off the insulation of the cable. The terminal has a stamping structure like a "knife edge", which directly punctures the insulation layer and contacts the copper core when pressed down. Process: This type of terminal requires extremely high precision for the cutting edge of the stamping mold, and the insulation skin must be cut at once, but the copper wire cannot be cut.

5. Armoring Although the metal layer of armored cables is usually wrapped, the related accessories are stamped. Armor joint accessories: used to fix the locking plate and grounding ring of the armor steel strip. Wire protection sleeve joint: a joint between a metal hose (used to protect cables) and equipment, with a locking claw usually made of stamped parts. Why can't the cable industry do without stamping? Processing of conductive materials: Cable connectors must be made of copper (with good conductivity) or copper alloy (with elasticity). These materials have good ductility and are very suitable for stamping processing, but not suitable for cutting (copper is too soft, cutting is easy to stick to the knife and wastes materials). Massive production: The number of terminals consumed globally each year is in the trillions. Only high-speed stamping molds (hundreds to thousands of times per minute) can meet this astronomical demand for production capacity. Elastic contact: The reason why plugs and sockets can make close contact is due to the elasticity of metal. The stamping process combined with high-performance copper alloy can produce contact springs with perfect rebound force.

summary In the cable industry, metal stamping parts are the "nodes". The cable itself is the "road", while the stamped parts are the "toll station" (connector), "guardrail" (fixing clip), and "terminal station" (terminal) on the road. Without stamped parts, cables cannot complete the final delivery of electrical energy and signals.
